Epson BrightLink 536Wi Short Throw LCD Projector - 16:10 - White

  • SKU: ETE-1107|MFG PART: V11H670022

$1,463.79

1280 x 800 - Front - 720p - 5000 Hour Normal Mode - 10000 Hour Economy Mode - WXGA - 16,000:1 - 3400 lm - HDMI - USB - VGA In - Network (RJ-45) - 2 Year Warranty
  • These LCD projectors can be used in large rooms where a greater projection distance is needed
  • Experience the action with the brightness you need to fill the screen with vibrant visualizations
  • Delivers high-quality widescreen performance in any settings with the WXGA graphic mode on
  • The 16,000:1 contrast ratio gives depth to your visuals
View Product Overview

PRODUCT OVERVIEW

1280 x 800 - Front - 720p - 5000 Hour Normal Mode - 10000 Hour Economy Mode - WXGA - 16,000:1 - 3400 lm - HDMI - USB - VGA In - Network (RJ-45) - 2 Year Warranty
  • These LCD projectors can be used in large rooms where a greater projection distance is needed
  • Experience the action with the brightness you need to fill the screen with vibrant visualizations
  • Delivers high-quality widescreen performance in any settings with the WXGA graphic mode on
  • The 16,000:1 contrast ratio gives depth to your visuals

additional information

Projection Method:
Front
Interactive:
Yes
Throw Type:
Short Throw
Maximum Focal Length:
6.40 mm
Maximum Diagonal Image Size:
113
Number of Lamps:
1
Lamp Type:
UHE
Lamp Power:
215 W
Normal Mode Lamp Life:
5000 Hour
Economy Mode Lamp Life:
10000 Hour
Standard Mode Brightness:
3400 lm
Native Resolution:
1280 x 800
Graphic Mode:
WXGA
Maximum Resolution:
1600 x 1200
Native Aspect Ratio:
16:10
Contrast Ratio:
16,000:1
Video Signal Standard:
HDTV
Output Scan Format:
720p
HDMI:
Yes
USB:
Yes
Network (RJ-45):
Yes
S-Video:
Yes
Operating Power Consumption:
344 W
Form Factor:
Wall Mountable
Height:
6.2
Width:
13.6
Depth:
11.7
Weight (Approximate):
8.50 lb
Application/Usage:
Education
Limited Warranty:
2 Year

Why this product?

The short-throw interactive projector for collaboration in any classroom

The BrightLink 536Wi short-throw interactive projector offers exciting, collaborative learning for any classroom - without requiring an electronic whiteboard. Transform any wall or existing dry-erase board into an interactive display. Delivering 3x Brighter Colors than competitive models, Epson® 3LCD projectors ensure vivid images. Featuring 3400 lumens of color brightness and 3400 lumens of white brightness, the 536Wi shines bright. Project images up to 116 from 4' away with minimal shadows or glare. Moderator device management software enables instructors to wirelessly connect up to 50 devices and simultaneously share students' work - from computers, iOS® and Android™ devices. Plus, the 536Wi supports top education software.

TECHNICAL SPECIFICATIONS

Specifications

Manufacturer:
Epson Corporation
Manufacturer Part Number:
V11H670022
Manufacturer Website Address:
http://www.epson.com
Brand Name:
Epson
Product Line:
BrightLink
Product Model:
536Wi
Product Name:
BrightLink 536Wi Interactive WXGA 3LCD Projector
Product Type:
LCD Projector

Technical Information

Projection Method:
Front
Platform Supported:
PC,Mac
Interactive:
Yes

Projection Lens

Throw Type:
Short Throw
Maximum Focal Length:
6.40 mm
Minimum Diagonal Image Size:
59
Maximum Diagonal Image Size:
113
Maximum Lens Aperture:
F/1.6

Lamp

Number of Lamps:
1
Lamp Type:
UHE
Lamp Power:
215 W
Normal Mode Lamp Life:
5000 Hour
Economy Mode Lamp Life:
10000 Hour


Standard Mode Brightness:
3400 lm
Color Supported:
1.07 Million Colors
Native Resolution:
1280 x 800
Graphic Mode:
WXGA
Maximum Resolution:
1600 x 1200
Native Aspect Ratio:
16:10
Throw Ratio:
0.48 to 0.65
Contrast Ratio:
16,000:1
Vertical Keystone Correction:
-7°/+7°
Horizontal Keystone Correction:
-5°/+5°
Digital Zoom:
1.35x

Video

Video Signal Format:
NTSC,PAL,SECAM
Video Signal Standard:
HDTV
Input Scan Format:
1080i
Output Scan Format:
720p

Audio

Number of Speakers:
1
Speaker Output Power:
16 W
Speaker Output Mode:
Mono

Network & Communication

Ethernet Technology:
Ethernet

Interfaces/Ports

HDMI:
Yes
Total Number of HDMI Ports:
1
Number of USB Ports:
2
USB:
Yes
Composite Video:
Yes
Network (RJ-45):
Yes
S-Video:
Yes
VGA In:
Yes
VGA Out:
Yes
Number Of Audio Inputs:
2
Audio Line In:
Yes
Number Of Audio Outputs:
1
Audio Line Out:
Yes
Serial Port:
Yes

Power Description

Input Voltage:
120 V AC,230 V AC
Operating Power Consumption:
344 W
Standby Power Consumption:
280 mW

Physical Characteristics

Color:
White
Form Factor:
Wall Mountable
Height:
6.2
Width:
13.6
Depth:
11.7
Weight (Approximate):
8.50 lb

Miscellaneous

Application/Usage:
Education
Package Contents:
  • BrightLink 536Wi Interactive WXGA 3LCD Projector
  • Interactive Pen A (Orange)
  • USB Cable
  • Easy Interactive Software
  • User's Guide CD
  • Rechargeable Batteries and Charger
  • Quick Setup Guide
  • Power Cord
  • Computer Cable (VGA)
  • Projector Remote Control
  • Batteries
  • User Manual CD
  • Projector Software CD
  • Quick Setup Sheet
  • Password Protection Sticker
  • Lens Cover

Warranty

Limited Warranty:
2 Year
Parts Warranty/Labor:
3 Month - Lamp
