Hitachi MP-WU5503 LCD Projector - 16:10

  • SKU: HTE-2024|MFG PART: MPWU5503

$2,715.09

1920 x 1200 - Front, Ceiling - 1080p - 20000 Hour Normal ModeWUXGA - 1,500,000:1 - 5000 lm - HDMI - USB - 3 Year Warranty
  • 3LCD Laser Projector
  • WUXGA 1920 x 1200
  • 5,000 ANSI Lumens Brightness
  • 1,500,000:1 Contrast Ratio
  • 50,000 Hours Light Source Life (Long life 2 mode)
View Product Overview

PRODUCT OVERVIEW

1920 x 1200 - Front, Ceiling - 1080p - 20000 Hour Normal ModeWUXGA - 1,500,000:1 - 5000 lm - HDMI - USB - 3 Year Warranty
  • 3LCD Laser Projector
  • WUXGA 1920 x 1200
  • 5,000 ANSI Lumens Brightness
  • 1,500,000:1 Contrast Ratio
  • 50,000 Hours Light Source Life (Long life 2 mode)

additional information

Projection Method:
Front,Ceiling
Minimum Focal Length:
19.80 mm
Maximum Focal Length:
33.90 mm
Maximum Diagonal Image Size:
25 ft
Optical Zoom:
1.7x
Number of Lamps:
1
Lamp Type:
Laser
Normal Mode Lamp Life:
20000 Hour
Standard Mode Brightness:
5000 lm
Native Resolution:
1920 x 1200
Graphic Mode:
WUXGA
Native Aspect Ratio:
16:10
Contrast Ratio:
1,500,000:1
Video Signal Standard:
HDTV
Output Scan Format:
1080p
HDMI:
Yes
USB:
Yes
Operating Power Consumption:
370 W
Height:
5.3
Width:
19.9
Depth:
16.7
Weight (Approximate):
18 lb
Limited Warranty:
3 Year

Why this product?

Maxell expands solid state projector line with a 5,000 ANSI lumens, 3-chip LCD model delivering larger-than-life performance.

Maxell's solid state light source projector line now includes the laser light source 3LCD model MP-WU5503 with 5,000 ANSI lumens. The new laser phosphor light source offers approximately 20,000 hours (normal mode) of operation time and is virtually maintenance free, there is no lamp to replace providing a dramatic reduction in total cost of ownership. Ideal for digital signage applications, as well as a perfect choice for auditoriums, lecture halls, large classrooms, conference rooms and museums. Plus, 5,000 ANSI lumens brightness and 1,500,000:1 contrast ratio results in super bright display with outstanding image clarity and uniformity. Additionally a suite of advanced features includes High Dynamic Contrast Range (HDCR2), 2 HDMI ports, and Maxell's original technology Accentualizer. As with all Maxell projectors, you can expect vibrant image quality, cost-efficient operation, and long-lasting reliability. For added piece of mind, Maxell's MP-WU5503 is also backed by a generous 3-year warranty and our world-class service and support programs.

Long Life 20,000 Hours Laser Light Source
Light source combines blue laser diodes and phosphor which can achieve over 6,000 lumens. The projection image is bright and clear, with vivid colors. Since lamp replacement is unnecessary, maintenance cost is reduced and by not using mercury lamps, the projectors are eco-friendly.

Plus, Maxell's unique cooling system can achieve a low noise level of 27dB in whisper mode. The life of the light source is approximately 20,000 hours at normal mode but by using other modes which reduce the brightness or operation period, its life can be extended up to 50,000 hours. These mode settings can be used for different purposes depending on the application of the projector.

TECHNICAL SPECIFICATIONS

Specifications

Manufacturer:
Hitachi, Ltd
Manufacturer Part Number:
MPWU5503
Manufacturer Website Address:
http://www.hitachi.us
Brand Name:
Hitachi
Product Model:
MP-WU5503
Product Name:
MP-WU5503 LCD Laser Projector
Product Type:
LCD Projector

Technical Information

Projection Method:
Front,Ceiling

Projection Lens

Minimum Focal Length:
19.80 mm
Maximum Focal Length:
33.90 mm
Maximum Diagonal Image Size:
25 ft
Optical Zoom:
1.7x

Lamp

Number of Lamps:
1
Lamp Type:
Laser
Normal Mode Lamp Life:
20000 Hour


Standard Mode Brightness:
5000 lm
Native Resolution:
1920 x 1200
Graphic Mode:
WUXGA
Native Aspect Ratio:
16:10
Contrast Ratio:
1,500,000:1

Video

Video Signal Standard:
HDTV
Output Scan Format:
1080p

Interfaces/Ports

HDMI:
Yes
USB:
Yes

Power Description

Operating Power Consumption:
370 W

Physical Characteristics

Height:
5.3
Width:
19.9
Depth:
16.7
Weight (Approximate):
18 lb

Miscellaneous

Package Contents:
  • MP-WU5503 LCD Laser Projector
  • Remote Control
  • Power Cord
  • Computer Cable
  • 2 x AA Batteries
  • Security Label
  • Lens Cover
  • Hook Metal
  • HDMI Cable Holder
  • 2 x Cable Tie for HDMI
  • 1 x Cable Tie for Power
  • User's Manual (concise)

Warranty

Limited Warranty:
3 Year
