Lenovo ThinkVision E22-20 21.5" Full HD WLED LCD Monitor - 16:9 - Raven Black

  • SKU: LTE-1034|MFG PART: 62A4MAR4US

$170.99

22" Class - In-plane Switching (IPS) Technology - 1920 x 1080 - 16.7 Million Colors - 250 Nit Typical - 14 ms - 60 Hz Refresh Rate - HDMI - VGA - DisplayPort
  • 14 ms response time provides flicker-free video and images for your viewing pleasure
  • 16:9 widescreen resolution perfect for watching movies, playing video games and getting on with office work
View Product OverviewView Reviews

PRODUCT OVERVIEW

22" Class - In-plane Switching (IPS) Technology - 1920 x 1080 - 16.7 Million Colors - 250 Nit Typical - 14 ms - 60 Hz Refresh Rate - HDMI - VGA - DisplayPort
  • 14 ms response time provides flicker-free video and images for your viewing pleasure
  • 16:9 widescreen resolution perfect for watching movies, playing video games and getting on with office work

additional information

Number of Screens:
1
Screen Size Class:
22
Viewable Screen Size:
21.5
Screen Mode:
Full HD
Panel Technology:
In-plane Switching (IPS) Technology
Response Time:
14 ms
Aspect Ratio:
16:9
Pixel Pitch:
9.8 mil
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Mount Type:
Desk Mountable
Backlight Technology:
WLED
Features:
On-screen Display (OSD),Anti-glare,Eye-Care,Cable Lock Slot
Stand Adjustments:
Height,Tilt,Pivot
Adjustable Stand Height:
Yes
Maximum Resolution:
1920 x 1080
Standard Refresh Rate:
60 Hz
Color Supported:
16.7 Million Colors
Native Contrast Ratio:
1,000:1
Dynamic Contrast Ratio:
3,000,000:1
Brightness:
250 Nit - Typical
Color Gamut:
72% NTSC (CIE 1931)
Number of Speakers:
2
Speakers:
Yes
Wireless LAN:
No
Bluetooth:
No
Network (RJ-45):
No
HDMI:
Yes
USB:
No
VGA:
Yes
DisplayPort:
Yes
Number of HDMI Inputs:
1
Number of DisplayPorts:
1
Webcam:
No
Operating Power Consumption:
24 W
Energy Consumption per Year:
35.6 kWh
Energy Efficiency Class (till 28th February, 2021):
A++
VESA Mount Compatible:
Yes
Color:
Raven Black
Height:
12.1
Width:
20
Depth:
1.7
Height with Stand:
17.46
Width with Stand:
20
Depth with Stand:
7.03
Weight (Approximate):
4.85 lb
Weight with Stand (Approximate):
8.60 lb
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
TCO 8.0,TCO Certified Edge Displays 2.0,EU RoHS,EPEAT Silver,China Energy Efficiency Standard Tier 1,RoHS
Limited Warranty:
3 Year

Why this product?

Overview

The ThinkVision E22-20 is a user-orientated device, designed with modern workforce requirements in mind. Boost productivity with this 21.5-inch Full-HD display that delivers clear and accurate visuals, no matter the task. The ports on offer-HDMI, DP, and VGA-allow for versatile connectivity. Most of all, its ergonomic design with a lift range of 155 mm not only optimises office space, but also ensures you experience minimal fatigue while on the job.

TECHNICAL SPECIFICATIONS

Specifications

Manufacturer:
Lenovo Group Limited
Manufacturer Part Number:
62A4MAR4US
Manufacturer Website Address:
http://www.lenovo.com/us/en/
Brand Name:
Lenovo
Product Line:
ThinkVision
Product Model:
E22-20
Product Name:
ThinkVision E22-20 22 Monitor
Product Type:
LCD Monitor

Technical Information

Number of Screens:
1
Screen Size Class:
22
Viewable Screen Size:
21.5
Screen Mode:
Full HD
Panel Technology:
In-plane Switching (IPS) Technology
Response Time:
14 ms
Aspect Ratio:
16:9
Pixel Pitch:
9.8 mil
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Mount Type:
Desk Mountable
Backlight Technology:
WLED
Features:
On-screen Display (OSD),Anti-glare,Eye-Care,Cable Lock Slot
Stand Adjustments:
Height,Tilt,Pivot
Adjustable Stand Height:
Yes

Video

Maximum Resolution:
1920 x 1080
Standard Refresh Rate:
60 Hz
Color Supported:
16.7 Million Colors
Native Contrast Ratio:
1,000:1
Dynamic Contrast Ratio:
3,000,000:1
Brightness:
250 Nit - Typical
Color Gamut:
72% NTSC (CIE 1931)

Audio

Number of Speakers:
2
Speakers:
Yes

Network & Communication

Wireless LAN:
No
Bluetooth:
No

Interfaces/Ports

Network (RJ-45):
No
HDMI:
Yes
USB:
No
VGA:
Yes
DisplayPort:
Yes
Number of HDMI Inputs:
1
Number of DisplayPorts:
1

Built-in Devices

Webcam:
No

Power Description

Operating Power Consumption:
24 W
Energy Consumption per Year:
35.6 kWh
Energy Efficiency Class (till 28th February, 2021):
A++

Physical Characteristics

VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Color:
Raven Black
Height:
12.1
Width:
20
Depth:
1.7
Height with Stand:
17.46
Width with Stand:
20
Depth with Stand:
7.03
Weight (Approximate):
4.85 lb
Weight with Stand (Approximate):
8.60 lb

Miscellaneous

Package Contents:
  • ThinkVision E22-20 22 Monitor
  • Stand
  • 1 x Power Cable (1.8 m)
  • 1 x HDMI Cable (1.8 m)
  • Quick Setup Guide
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
TCO 8.0,TCO Certified Edge Displays 2.0,EU RoHS,EPEAT Silver,China Energy Efficiency Standard Tier 1,RoHS

Warranty

Limited Warranty:
3 Year
