Viewsonic LS831WU Ultra Short Throw DLP Projector

  • SKU: VVS-13200|MFG PART: LS831WU

$2,619.72

1920 x 1200 - Front, Ceiling - 20000 Hour Normal ModeWUXGA - 3,000,000:1 - 4500 lm - HDMI - USB
  • 0.25 ultra short throw for space saving installation
  • 2nd generation Laser Phosphor technology with 20,000 hours lifespan
  • 4,500 ANSI Lumens offering bright images in any environment
  • Larger screen size with lower cost-per-inch
  • Cost-effective built-in HDBaseT receiver
View Product Overview

PRODUCT OVERVIEW

1920 x 1200 - Front, Ceiling - 20000 Hour Normal ModeWUXGA - 3,000,000:1 - 4500 lm - HDMI - USB
  • 0.25 ultra short throw for space saving installation
  • 2nd generation Laser Phosphor technology with 20,000 hours lifespan
  • 4,500 ANSI Lumens offering bright images in any environment
  • Larger screen size with lower cost-per-inch
  • Cost-effective built-in HDBaseT receiver

additional information

Projection Method:
Front,Ceiling
Throw Type:
Ultra Short Throw
Maximum Diagonal Image Size:
16.67 ft
Number of Lamps:
2
Lamp Type:
Laser/Phosphor
Lamp Power:
67 W
Normal Mode Lamp Life:
20000 Hour
Standard Mode Brightness:
4500 lm
Native Resolution:
1920 x 1200
Graphic Mode:
WUXGA
Maximum Resolution:
3840 x 2160
Contrast Ratio:
3,000,000:1
Video Signal Standard:
HDTV
HDMI:
Yes
USB:
Yes
Operating Power Consumption:
504 W
Height:
6.2
Width:
19.4
Depth:
15.2
Weight (Approximate):
21.83 lb

Why this product?

ViewSonic's LS831WU is an advanced 4,500 ANSI Lumens WUXGA ultra short throw installation projector perfect for public and commercial display applications. With a 0.25 throw ratio, users can easily get 100 screen from only 21 cm away. Screen size can further be expanded to up to 150 at a lower cost-per-inch compared to commercial displays. Adopting the 2nd generation laser phosphor technology, it offers consistent high brightness for a reliable 20,000 hours lifespan. Built-in HDBaseT receiver and 360° projection capability together ensure the ease of use desired. The embedded 20W cube speakers offer powerful audio right out of the box with three fine-tuned audio modes suitable for different application scenarios.

TECHNICAL SPECIFICATIONS

Specifications

Manufacturer:
Viewsonic Corporation
Manufacturer Part Number:
LS831WU
Manufacturer Website Address:
http://www.viewsonic.com
Brand Name:
Viewsonic
Product Model:
LS831WU
Product Name:
4,500 ANSI Lumens WUXGA Ultra Short Throw Laser Installation Projector
Product Type:
DLP Projector

Technical Information

Projection Method:
Front,Ceiling

Projection Lens

Throw Type:
Ultra Short Throw
Maximum Diagonal Image Size:
16.67 ft

Lamp

Number of Lamps:
2
Lamp Type:
Laser/Phosphor
Lamp Power:
67 W
Normal Mode Lamp Life:
20000 Hour


Standard Mode Brightness:
4500 lm
Native Resolution:
1920 x 1200
Graphic Mode:
WUXGA
Maximum Resolution:
3840 x 2160
Contrast Ratio:
3,000,000:1

Video

Video Signal Standard:
HDTV

Interfaces/Ports

HDMI:
Yes
USB:
Yes

Power Description

Operating Power Consumption:
504 W

Physical Characteristics

Height:
6.2
Width:
19.4
Depth:
15.2
Weight (Approximate):
21.83 lb

Miscellaneous

Package Contents:
  • 4,500 ANSI Lumens WUXGA Ultra Short Throw Laser Installation Projector
  • 1 x Power Cord
  • 1 x VGA Cable
  • 1 x Remote Control
  • 1 x QSG
